Cell O con Dry Mix Mortar Bricks
INTRODUCTION TO DRY MIX MORTAR
CELL O CON Dry Mix Mortar for bricks is amongst the most versatile material used in modern construction industry. It serves to lay bricks & other masonry blocks, coat building as renders & skim coat & fix tiles. Now a days all Indian & Foreign construction Industries are demanding for new improved building material. The modern CELL O CON Dry Mix Mortar are produced in a special factory with dedicated facilities on batching & blending of all the necessary ingredients in highly – controlled process. In this way, different types of CELL O CON Dry Mix Mortar products with well – defined properties & performance to meet specific requirement and application can be produced. Today the CELL O CON Dry Mix Mortar is conquering the market by replacing the traditional job site mixing mortar because of its various advantages.
Methra Industries is manufacturing CELL O CON Dry Mix Mortar in specially designed dry mix mortar plants in which binders and aggregate are mixed in the appropriate way and transportation to construction site is done through bags or silos. It needs only be mixed with water prior to use. This factory based process also allows different additives and admixtures to be added to these mortars to improve significantly their technical performance. Based on this technology individual Dry Mix Mortar for specific application can be produced. Addition of Admixtures into the Dry Mix Mortar will give maximum technical properties such as workability, consistency, water retention of mix and also hardened mortar property that is compressive strength and bond strength.
Advantages of of Cell O Con Dry Mix Mortar for bricks
- Reduced shrinkage cracks through better cement hydration
- No delaminating or pop-out on smooth or concrete surface due to very good bond strength
- Good workability and sag resistance
- Very good compressive flexural and tensile strength than ASTM standard values
- Good water resistance property
- Better flexibility
- Consistent quality
- Easy to mix and apply
- Better finish and surface appearance
- Almost nil wastage of the material at site
- Minimum space required for the storage
- Inventory cost saving
- No multiple raw material (sand, cement and additives)
- Minimum supervision requires
CELL O CON DRY MIX MORTAR PRODUCTS
- Cell O Con External plaster
- Cell O Con internal plaster
- Cell O Con AAC Blocks and Brick joining mortar
- Cell O Con Tile adhesives
- Cell O Con Water proofing mortar
- Cell O Con Grouts
- Cell O Con Floor screeds
- Cell O Con Bonding mortar
- Cell O Con Wall putty
- Cell O Con Gypsum based internal plaster
ADVANTAGES
- “Ready to use dry mix mortar for bricks, requires only water in addition”. Excellent adhesion and good anti-sagging property.
- “Versatile to used as brick laying mortar to minimize hair line cracks caused due to material shrinkage” that provides uniform & high strength and smooth surface finish.
- “Thin bed application helps in clean and neat laying practice” resulting in considerable saving in material consumption.
- Economical as a result of fast installation.
METHOD OF APPLICATION
Surface Preparation :
To ensure proper adhesion the surface of blocks should be free from dust, oil and other loose particles.
Mixing :
Mix CELL O CON Light weight dry mix mortar supplied in bags with potable water only, in a clean plastic bucket or a clean non corrosive uncontaminated metal tub.
Use an electric agitator or paddle mixer to ensure a block work and uniform mix. The amount of water required for addition is approximately 30% by weight. Add light weight Cell O Con Dry mix mortar to water, turn the contents of the bag carefully and stir frequently. After mixing, allow to stand for 5 minutes and mix again before applying. No further water addition is required to the mix. Please dont remix or reuse hard or set mortar.
Application :
Apply CELL O CON Mixed light weight dry mix mortar to the required thickness 3 to 5 mm by means of a trowel and levelled. CELL O CON Dry Mix Mortar demonstration team will assist in these procedures upon request.
Storage :
Always store CELL O CON light weight dry mix mortar in a dry place, off the ground and well covered. Reject hard or lumpy material.
Cleaning :
Clean tools and equipments promptly with clean water.
Shelf Life :
CELL O CON Dry mix mortar’s shelf life is 6 Months in tightly sealed bags
Packaging : 30 kg bags / 40 kg bags
CELL O CON DRY MIX MORTAR - TECHNICAL DATA
Supply form Cementitious Grey Power Application Thickness 3-5 mm, Binders Portland cement & Polymers, Selected graded aggregates with Filler maximum 3mm grain size, water requirement 6.0-6.5 litres / 30 kg bag.
Density ASTM C185 : Dry= 1.3 kg / litre, Wet = 1.5 kg / litre
Compressive Strength ASTM C109 : < 4N / mm²
Splitting Tensile strength ASTM C1006 : 0.37 Mpa average @ 28 days for AAC Blocks of average compressive strength of 3.5 N / mm²
Flexural Strength : 0.57 N/mm²
Initial Shear Strength : > 0.15 N/mm²
Bond Strength : 0.8 N/mm²
Fire Resistance : Class A1, Freeze & Thaw resistance passes the requirements
Water retention BS 4551 : > 95%, Drying shrinkage
ASTM C531 : < 0.1%, Yields-17.5 litre / 30 kg bag depends Coverage on block size, Working Time 45 Minutes, self-curing, No curing is required after post construction.
CELL O CON DRY MIX MORTAR FOR BRICKS
A good Mortar needs to have strong adhesion to the underlying AAC Blocks with excellent water resistant, workability and Durability properties, that will protect the cracks formation in the walls, minimize the inconvenience of maintenance and speeds up the construction.
ADVANTAGES
- Reduced Shrinkage Cracks through better cement Hydration.
- “Ready to use dry mix mortar, requires only water addition”
- Excellent adhesion and good anti- sagging property.
- Versatile to use as AAC Block laying mortar.
- Minimize hair line cracks caused due to material shrinkage, uniform & high strength and smooth surface finish.
- Thin bed application helps in clean and neat laying practice, resulting in considerable saving in material consumption.
- Economical as a result of fast installation
PREPARATION, MIXING AND APPLICATION
SURFACE PREPARATION :
To ensure proper adhesion the surface of blocks should be free from dust, Oil and other Loose particles.
MIXING :
Mix CELL O CON Light weight dry mix mortar supplied in bags with potable water only, in a clean plastic bucket or a clean non corrosive uncontaminated metal tub. Use an electric agitator or paddle mixer to ensure a block work and uniform mix. Add is approximately 30% of water by weight, add light weight Cell O Con Dry mix mortar to water, turn the contents of the bag carefully and stir frequently. Once mixed, allow to stand for 5 minutes and mix again before applying. No further water addition is needed to the mix. Hard or set mortar should not be remixed or reused
APPLICATION :
CELL O CON Mixed light weight dry mix mortar can be applied to the required thickness 3 to 5mm by means of a trowel and levelled. CELL O CON Dry Mix Mortar demonstration team will assist in these procedures upon request.
STORAGE :
Store CELL O CON light weight dry mix mortar in a dry place, off the ground and well covered. Hard or lumpy material must be rejected.
CLEANING :
Clean tools and equipments promptly with clean water.
SHELF LIFE :
CELL O CON Dry mix mortar’s shelf life is 6 Months in tightly sealed bags.
PACKAGING : 40 Kg bags.
BENEFITS
HIGH STRENGTH – High Compressive and tensile strength increase masonry strength.
EASY APPLICATION – The material is pre-mixed and only water has to be added on site. This makes the process of plastering much easier and quicker capacity.
MINIMUM CRACKS – Shrinkage cracks are minimized as premix Mortar raw materials is tested and accurately mixed with specific particle size and quantity with additives.
HIGHER COVERAGE – Due to lower density and high volume, it covers 15-20 sqft / bag 40kg.
PREMIXED – No site mix and blending of powder is required. Only water to be added.
HASSLE FREE – Easy and hassle free in maintaining mortar ratio, whereas in the traditional method labour and supervision is required to prepare the mix.
MISSING WASTAGE – The wastage caused in the traditional site mix process in which sand sieving and mixing mortar is totally avoided.
STORAGE – Easy to maintain stock as equal size packaging in bag form is provided.
FINISH – Surface finish after application is excellent and uniform due to best particle size grading.
ALL ROUND YEAR – Dry mix Mortar is available the whole year without any uncertainty.
CONSISTENCY – Dry mix mortar with right mix of recipe and quantity at its best comparison chart parameters.
